The fully equipped Metrology Lab inside the Center for Manufacturing Advancement (CMA) provides the integrated inspection capabilities required to validate product quality. Equipped with one of the largest Coordinate Measuring Machines (CMM) on the East Coast and a bevy of other top-tier qualification tools and equipment, the lab can provide a variety of metrology services to manufacturers.

Clients and partners of the CMA Metrology Lab can expect reliable services and results.

Request ISO-Certified Metrology Services

Manufacturers who need testing support can:

  • Accurately and affordably measure and certify products.
  • Bypass the cost and process of establishing an inspection lab in new facilities.
  • Bypass the requirement to send products to an outside lab, thus saving time and money.

The Metrology Lab is housed inside the Center for Manufacturing Advancement (CMA) on the campus of the Institute for Advanced Learning and Research (IALR). This measurement lab is controlled according to strict industry standards and offers National Institute of Standards and Technology (NIST) certified inspection and is ISO 9001:2015 certified.

IALR owns the equipment and space while applications engineers with Mitutoyo and Master Gage & Tool Co. operate the equipment.

Inside the Certified Metrology Lab
Partner with the CMA
Utilize the Services of the ISO-Certified Metrology Lab
Contact Us Today

Metrology Lab Services

In the CMA Metrology Lab, application engineers can measure physical dimensions and provide qualifications of complex factors like shape, hardness, density and other physical qualities.

NIST-certified Services offered by the ISO-certified Metrology Lab include:

  • Contract inspection
  • CMM programming
  • Laser scanning
  • Automation integration
  • Reverse engineering
  • Calibration services
  • Application engineering support

Specialized Metrology Equipment

The Mitutoyo Crysta-Apex V163012 Coordinate Measuring Machine inside the CMA Metrology Lab can perform some of the most sophisticated yet critical measurement and qualification processes possible. While its work area can accommodate pieces as large as five feet wide, nearly 10 feet long and almost four feet tall, the space can also be used for smaller parts.

The CMM can perform any inspection that a company would need, and every measurement the machine makes is down to the micron.

The lab includes the following specialized equipment:

  • Mitutoyo Crysta-Apex V163012 CMM
  • Mitutoyo Crysta-Apex V9108 CMM
  • Mitutoyo RA-2200AH Circular Geometry Measuring System
  • Mitutoyo FTA-W8C4000-D Contour Measuring System
  • Mitutoyo FTA-W8S3000-D Surface Measuring System
  • Mitutoyo PH-3515 Optical Comparator
  • Mitutoyo QV-Apex 606 Vision Measuring System
  • Mitutoyo MF-UB2017D Measuring Microscope
  • Mitutoyo HR-530L Rockwell/Superficial Hardness Tester
  • Mitutoyo LH-600EG Linear Height Gage
  • Mitutoyo SJ-310 Surface Finish Analyzer

The Metrology Lab supports private and public industry as well as the Additive Manufacturing Center of Excellence – a Navy project housed inside the CMA.

Other CMA services include machining optimization support and digital manufacturing exploration.
